KPM VIT 100

KPM VIT 100 Specification

Batteries Type
AC Mains operated, plug-in (battery not required)

Usage & Applications
For voltage identification, insulation tests and field service

Accuracy
0.5% of reading

Pressure
Atmospheric (not for pressurized environments)

Resistant Feature
Shock, moisture, and dust resistant enclosure

Product Type
Voltage Indicator Tester

Material
Industrial-grade ABS and metal panel

Measuring Voltage Range
0 - 100V (VRMS)

Operating Temperature
-10C to +55C

Frequency (MHz)
50/60 Hz supported

Insulation Box
Yes, rugged molded insulation case

Protection System
Fuse protection with surge suppression

Size
Portable, compact

Color
Black case with silver panel

Dimension (L*W*H)
Approx. 420x340x185 mm

Weight
Approx. 6 kg

Safety Standard
Meets IEC safety standards

Switch Type
Rotary and push-button for operation mode selection

Environment
Indoor/outdoor professional industrial use

Display Type
Analog/Digital (confirm with manufacturer as image shows both possible indications)

Power Supply
230V AC, 50/60Hz / Mains Operated

Special Features
Quick-access foam lined protective cover

Panel Features
Integrated indicator lights and function switches

Mount Type
Portable, with handle for easy transport

Input Connection
Terminal and test lead provision

Carrying Case
High-impact resistant and waterproof carry case

About KPM VIT 100

Information :

The KPM VIT-100 (Vacuum Interrupter Tester) is applied for vacuum interrupter or vacuum interrupter circuit breaker high-voltage withstand tests. The test results are used to determine whether the VI or the VI of the circuit breaker is still in a healthy condition. The tester can generate DC high voltage up to 60kV on both sides of the VI. At the same time, it samples and displays the leakage current flowing through the VI. The leakage current value is used to evaluate whether the VI remains in good condition.

The KPM VIT-100 (Vacuum Interrupter Tester) is smart, compact, and lightweight. Its operation is also very simple, making it an ideal tool for vacuum circuit applications in power utility construction and maintenance departments. It can also be used as a quick quality control tool for vacuum interrupter and circuit breaker manufacturers for VI high-voltage withstand tests.

Information :

Robust Design for Industrial Environments

Encased in a high-impact, waterproof ABS and metal housing, the KPM VIT 100 is engineered for professional-grade reliability. It's resistant to shocks, moisture, and dust, ensuring consistent performance in harsh outdoor and indoor environments. The unit also features a molded insulation box and a quick-access, foam-lined protective cover for maximum device protection and user safety.

Convenient and Portable Field Operation

The KPM VIT 100 is designed for ease of transport and field use, featuring a sturdy carry handle and compact dimensions (approx. 420x340x185 mm, weighing around 6 kg). The integrated rotary and push-button switches, indicator lights, and a portable panel make it perfect for technicians needing quick setup and swift operation in various locations.

Versatile Measurement and Application

With a measuring voltage range of 0-100V VRMS and operating temperatures from -10C to +55C, this device covers a broad spectrum of voltage identification and insulation test applications. It operates directly from an AC mains supply (no batteries required), making it reliable for continuous industrial use without power interruptions.

FAQ's of KPM VIT 100:

Q: How do I operate the KPM VIT 100 for voltage identification and insulation testing?

A: To operate the KPM VIT 100, connect your test leads or terminals as specified, select the required function using the rotary and push-button switches, and view measurements on the analog/digital display. Ensure the mains power supply (230V AC) is properly connected before use.

Q: What environments is the KPM VIT 100 suitable for?

A: This instrument is designed for professional indoor and outdoor industrial environments. Its shock, moisture, and dust-resistant enclosure, along with compliance with IEC safety standards, makes it ideal for demanding field conditions.

Q: When should I use the KPM VIT 100 over other insulation testers?

A: The KPM VIT 100 is best used when you require precise voltage identification and insulation tests in field or industrial settings, particularly where portability, ruggedness, and direct AC mains operation are needed. Its high accuracy and robust protection features give it an edge in challenging environments.

Q: Where can the KPM VIT 100 be transported and stored safely?

A: Thanks to its compact size, sturdy handle, and waterproof carry case, the KPM VIT 100 can be easily transported between job sites and securely stored even in harsh locations. The foam-lined protective cover further guards the unit during transit.

Q: What is the process for connecting the input leads to the KPM VIT 100?

A: Input leads can be connected via dedicated terminal and test lead provisions on the device's panel. Always ensure secure and correct connections before activating the testing functions to guarantee accurate measurements and safety.

Q: What are the key benefits of using the KPM VIT 100 in the field?

A: The KPM VIT 100 provides robust protection, high measurement accuracy, and portability, ensuring reliable voltage identification and insulation testing on site. It is trusted for quick setup, easy operation, and suitability in various industrial scenarios.

Q: Does the KPM VIT 100 require batteries for operation?

A: No, the KPM VIT 100 operates directly from a 230V AC mains supply and does not require batteries. This feature ensures continuous operation without downtime from depleted batteries.
