KPM CT/PT Analyzer C+

KPM CT/PT Analyzer C+ Specification

Accuracy
0.05 %

Usage & Applications
Industrial

Material
SS

Measuring Voltage Range
300 Volt (v)

Size
6.4inches

Warranty
1 Year

KPM CT/PT Analyzer C+ Trade Information

Minimum Order Quantity
1 Set

Supply Ability
10 Sets Per Month

Delivery Time
5-7 Days

About KPM CT/PT Analyzer C+

Information :

KPM-CT/PT AnalyzerC+ Instrument transformer analyzer can carry out a series of standard tests quickly, such as determining the magnetization characteristic, saturation behavior (ALF/FS), transformation ratio and its accuracy, polarity,

load, winding resistance, or remanence. Tests are performed in accordance with standards: IEC60044-1, IEC60044-6, IEC 61869, ANSI/IEEE C57.13.1.

Low testing time (Completes all basic test for CT Winding & Cores in

few minutes )

Simple connection (Simple one time connection)
Highest accuracy (0.02% typ & 0.05% gtd. for turns ratio error )
Portable & light weight ( < 14KG )
High interference rejection (Can be used in 220/400/765 KV Live Switchyards )
Real time display of measurement ( For analysis purpose )
Multi Tap Testing (opt ) ( test all the ratios of a secondary winding in one go )
